Thursday, July 7, 2022

Microsoft Office 365 functionality that can ransom files stored on SharePoint and OneDrive

Ransomware attacks have traditionally targeted data across endpoints or network drives. Until now, IT and security teams felt that cloud drives would be more resilient to ransomware attacks. After all, the now-familiar “AutoSave” feature along with versioning and the good old recycle bin for files should have been sufficient as backups.  However, that may not be the case for much longer.

Proofpoint has discovered a potentially dangerous piece of functionality in Office 365 or Microsoft 365 that allows ransomware to encrypt files stored on SharePoint and OneDrive in a way that makes them unrecoverable without dedicated backups or a decryption key from the attacker.

Our research focused on two of the most popular enterprise cloud apps – SharePoint Online and OneDrive within the Microsoft 365 and Office 365 suites and shows that ransomware actors can now target organizations’ data in the cloud and launch attacks on cloud infrastructure.

Cloud ransomware attack chain

The Attack Chain

The Proofpoint team has identified the attack chain and documented the steps below. Once executed, the attack encrypts the files in the compromised users’ accounts. Just like with endpoint ransomware activity, those files can then only be retrieved with decryption keys.

These actions can be automated using Microsoft APIs, command line interface (CLI) scripts and PowerShell scripts.

  1. Initial Access: Gain access to one or more users’ SharePoint Online or OneDrive accounts by compromising or hijacking users’ identities.
  2. Account Takeover & Discovery: The attacker now has access to any file owned by the compromised user or controlled by the third-party OAuth application (which would include the user’s OneDrive account as well).
  3. Collection & Exfiltration: Reduce versioning limit of files to a low number such as 1, to keep it easy. Encrypt the file more times than the versioning limit, in this case twice. This step is unique to cloud ransomware compared to the attack chain for endpoint-based ransomware. In some cases, the attacker may exfiltrate the unencrypted files as part of a double extortion tactic.
  4. Monetization: Now all original (pre-attacker) versions of the files are lost, leaving only the encrypted versions of each file in the cloud account. At this point, the attacker can ask for a ransom from the organisation.
Cloud ransomware attack chain diagram. The staging phase is unique to Microsoft environments.

Lists and document libraries: Microsoft terms for storage containers inside SharePoint Online sites and OneDrive accounts

A list is a Microsoft web part that stores content such as tasks, calendars, issues, photos, files, etc. within SharePoint Online. OneDrive accounts are mostly used to store documents. You will hear document library as the term most associated with OneDrive. A document library is a special type of list on a SharePoint site or OneDrive account where you can upload, create, update, and collaborate on documents with team members.

The version settings for lists and document libraries are both found under list settings. In the above cloud ransomware attack chain, when we describe the collection and exfiltration step, the attacker would modify the list settings, affecting all files contained within that document library.

Document library versioning mechanism

Every document library in SharePoint Online and OneDrive has a user-configurable setting for the number of saved versions, which the site owner can change, regardless of their other roles. They don’t need to hold an administrator role or associated privileges. This is found within the versioning settings under list settings for each document library.

By design, when you reduce the document library version limit, any further changes to the files in the document library will result in older versions becoming very hard to restore (see responsible disclosure and discussion).

There are two ways to abuse the versioning mechanism to achieve malicious aims – either by creating too many versions of a file or by reducing the version limits of a document library.

Edits that increment a version of a file include changes to the document contents, filename, file metadata and the file encryption status.

The method of too many file versions created works as such:

  • Staging: Most OneDrive accounts have a default version limit of 500. An attacker could edit files within a document library 501 times. Now, the original (pre-attacker) version of each file is 501versions old, and therefore no longer restorable.
  • Data encryption: Encrypt the file(s) after each of the 501 edits. Now all 500 restorable versions are encrypted. Organizations cannot independently restore the original (pre-attacker) version of the files even if they attempt to increase version limits beyond the number of versions edited by the attacker. In this case, even if the version limit was increased to 501 or more, the file(s) saved 501 versions or older cannot be restored.

Encrypting files 500+ times is unlikely to be seen in the wild. It requires more scripting and more machine resources while making your operation easier to detect than the next method.

The method of reducing document library versioning works as such:

  • Staging: Reduce document library versioning number to a low number such as 1, to keep it easy. This means only the most recent version of the file before the last edit is saved and can be restored by a user
  • Data Encryption: Edit each file twice – either by encrypting the file twice or a combination of encryption, major content changes and file metadata changes. This will ensure an organization cannot restore the original (pre-attacker) versions of the file without the decryption key from the attacker.

Setting the version limit to zero is red herring and will not delete the versions. The versions will be available to the user in one simple step. Reset the version limit or manually switch it off and back on.

Files stored in a hybrid state on both endpoint and cloud such as through cloud sync folders will reduce the impact of this novel risk as the attacker will not have access to the local/endpoint files. To perform a full ransom flow, the attacker will have to compromise the endpoint and the cloud account to access the endpoint and cloud-stored files.

Initial access to SharePoint Online and OneDrive user accounts

The three most common paths attackers would take to gain access to one or more users’ SharePoint Online or OneDrive accounts are:

  • Account compromise: Directly compromising the users’ credentials to their cloud account(s) through phishing, brute force attacks, and other credential compromise tactics
  • Third-party OAuth applications: Tricking a user to authorize third-party OAuth apps with application scopes for SharePoint or OneDrive access
  • Hijacked sessions: either hijacking the web session of a logged-in user or hijacking a live API token for SharePoint Online and/or OneDrive

Protecting your organization and sensitive data from actions leading to cloud ransomware with Proofpoint

Fortunately, many of the best practice recommendations that apply to endpoint ransomware protection will apply too when it comes to protecting your cloud environments.

First, turn on detection of risky file configuration changes for Office 365 accounts with Proofpoint CASB. While a user can accidentally change the setting, it’s not very common behavior. In the case that users changed it unknowingly, they should be made aware of it and ask that they increase the version limit. This will reduce the risk of an attacker compromising users and taking advantage of already low version limits for those users’ lists to ransom the organization.

Second, improve security hygiene around ransomware.

  • Very Attacked People: Identify and prioritise greater protection for the users who face the most number and most threatening cloud, email and web attacks with Proofpoint Targeted Attack Protection (TAP). These users can be outside your list of very important people such as executives and privileged users.
  • Access management: Maintain strong password policy, increase multi factor authentication (MFA) usage, & instill a least-privileges, principles-based access policy across cloud apps
  • Disaster recovery & backup: Update disaster recovery and data backup policies to reduce the losses in case of ransomware. Ideally, complete external backups of cloud files with sensitive data on a regular basis. Don’t rely only on Microsoft to provide backups through versioning of document libraries.
  • Cloud security: Detect & remediate account compromises & 3rd party application abuse. Proofpoint CASB integrates with Proofpoint Nexus Threat Graph and third-party threat intelligence to stop account takeovers and third-party application abuse.
  • Data loss prevention: Prevent sensitive data downloads and large-scale data downloads to unmanaged devices to reduce the potential for double extortion tactics in ransomware. Proofpoint CASB provides customisable policies to help you protect your data on unmanaged devices. Proofpoint Insider Threat Management enables you to teach negligent users better security practices and collect evidence on malicious insiders in case they make the configuration changes.

Last, you may want to add the following to your response and investigation in case the risky configurations change detectors are triggered.

  • Increase restorable versions for the affected document libraries in your M365 or O365 settings immediately
  • Identify if any previous account compromise or risky configuration change alerts for this Office 365 account
  • Hunt for suspicious third-party app activity. If found, revoke OAuth tokens for malicious or unused third-party apps in the environment
  • Identify if the user showcased previous out of policy behaviour patterns across cloud, email, web and endpoint (negligence with sensitive data, risky data manipulation and risky OAuth app actions etc.)

Responsible disclosure and discussion

Prior to this blog, Proofpoint followed Microsoft’s disclosure path and received a couple of responses.

Their claims are as follows:

  • The configuration functionality for versioning settings within lists is working as intended
  • Older versions of files can be potentially recovered and restored for an additional 14 days with the assistance of Microsoft Support.

However, Proofpoint attempted to retrieve and restore old versions through this process (i.e., with Microsoft Support) and was not successful. Secondly, even if the versioning settings configuration workflow is as intended, Proofpoint has shown that it can be abused by attackers towards cloud ransomware aims.
